List of Intel microprocessors

The possibility of replacement the processor depends on specific model of a notebook, a chipset (more precisely than the south bridge) and the processor set in a notebook!

Processors in the rPGA casing can be replaced in house conditions. Processors in the fcBGA casing are unsoldered on the notebook motherboard, their replacement is possible only in the presence of the equipment for BGA (ball grid array) of soldering.

It is necessary to pay attention, after changeover of the processor by more powerful - check compliance of the cooling system with a thermal packet of the set processor. The processor with the increased thermal packet (TDP) will give additional load of power supply unit of your notebook. It is in that case recommended to acquire power supply unit with the increased power. Also, a considerable role is played by quantity of phases of a supply of the processor on the motherboard. Often, the quantity of phases corresponds to the number of the chokes which are near CPU socket (you shouldn't forget about the choke which are used for the built-in graphics of the processor).

CPU-Z - the program which will help you with a choice of the suitable processor.

CPU-z program screenshot

Tab Mainboard has a section Southbridge, this parameter is necessary for selection of the suitable processor.


CPUs Intel® Core™ 1st gen

List of mobile Intel® Core™ microprocessors of the 1st generation
Socket G1 (rPGA988A) for Mobile Intel HM55 Chipset (SLGZS)


  • Dual Core (32 nm, 35 W)
Mobile Celeron P4x00: P4500 (2M Cache, 1.86 GHz), P4600 (2M Cache, 2.00 GHz);
Mobile Pentium P6x00: P6000 (3M Cache, 1.86 GHz), P6100 (3M Cache, 2.00 GHz), P6200 (3M Cache, 2.13 GHz), P6300 (3M Cache, 2.27 GHz);
Core i3-3x0M: i3-330M (3M Cache, 2.13 GHz), i3-350M (3M Cache, 2.26 GHz), i3-370M (3M Cache, 2.40 GHz), i3-380M(3M Cache, 2.53 GHz), i3-390M (3M Cache, 2.66 GHz);
Core i5-xx0M: i5-430M (3M Cache, 2.53 GHz), i5-450M (3M cache, 2.66 GHz), i5-460M (3M Cache, 2.80 GHz), i5-480M (3M Cache, 2.933 GHz), i5-520M (3M Cache, 2.933 GHz), i5-540M (3M Cache, 3.066 GHz), i5-560M (3M Cache, 3.20 GHz), i5-580M (3M Cache, 3.33 GHz);
Core i7-6x0M: i7-620M (4M Cache, 3.333 GHz), i7-640M (4M Cache, 3.46 GHz).


CPUs Intel® Core™ 2nd gen

List of mobile Intel® Core™ microprocessors of the 2nd generation Sandy Bridge
Socket G2 (rPGA988B) for Mobile Intel HM65 Chipset (SLJ4P), Intel HM67 Chipset (SLJ4N)

Chipsets of Intel HM65, Intel HM67 don't support 22-nanometer processors Ivy Bridge!

  • Single Core (Sandy Bridge, 32 nm, 35 W)
Mobile Celeron: B710 (1.5M Cache, 1.60 GHz), B720 (1.5M Cache, 1.70 GHz), B730 (1.5M Cache, 1.80 GHz).
  • Dual Core (Sandy Bridge, 32 nm, 17-35 W)
Mobile Celeron: B800 (2M Cache, 1.50 GHz), B810 (2M Cache, 1.60 GHz), B815 (2M Cache, 1.60 GHz), B820 (2M Cache, 1.70 GHz), B830 (2M Cache, 1.80 GHz), B840 (2M Cache, 1.90 GHz);
Mobile Pentium: B940 (2M Cache, 2.00 GHz, 35W), B950 (2M Cache, 2.10 GHz, 35W), B960 (2M Cache, 2.20 GHz, 35W), B970 (2M Cache, 2.30 GHz), B980 (2M Cache, 2.40 GHz), B987 (2M Cache, 1.50 GHz);
Core i3: 2308M, 2310M (3M Cache, 2.10 GHz), 2312M (3M Cashe, 2.1 GHz), 2328M (3M Cashe, 2.2 GHz), 2330E (3M Cashe, 2.2 GHz), 2330M (3M Cache, 2.20 GHz), 2348M (3M Cashe, 2.3 GHz), 2350M (3M Cashe, 2.3 GHz), 2370M (3M Cashe, 2.4 GHz);
Core i5: 2410M (3M Cache, 2.90 GHz), 2430M (3M Cache, 3.00 GHz), 2450M (3M Cache, 3.10 GHz), 2510E (3M Cache, 3.10 GHz), 2520M (3M Cache, 3.20 GHz), 2540M (3M Cache, 3.30 GHz);
Core i7: 2620M (4M Cache, 3.40 GHz), 2640M (4M Cache, 3.50 GHz);
  • Quad Core (Sandy Bridge, 32 nm, 45-55 W)
Core i7: 2630QM (6M Cache, 2.90 GHz), 2670QM (6M Cache, 3.10 GHz), 2710QE (6M Cache, 3.00 GHz), 2720QM (6M Cache, up to 3.30 GHz), 2760QM (6M Cache, 3.50 GHz), 2820QM (8M Cache, 3.40 GHz), 2860QM (8M Cache, 3.60 GHz).


CPUs Intel® Core™ 2nd и 3rd gen

List of mobile Intel® Core™ microprocessors of the 2nd and 3rd generation Sandy Bridge / Ivy Bridge
Socket G2 (rPGA988B) for Mobile Intel HM70 Chipset (SJTNV)

Chipset Intel HM70 don't support processors Core™ i3, Core™ i5, Core™ i7! The laptop turns off after 30 minutes!

The owners of notebooks with HM70 is possible to replace the HM75, HM76, HM77. After replacing the laptop will support the Intel Core i3 processors, Intel Core i5, Intel Core i7.

  • Single Core (Sandy Bridge, 32 nm, 35 W)
Mobile Celeron: B710 (1.5M Cache, 1.60 GHz), B720 (1.5M Cache, 1.70 GHz), B730 (1.5M Cache, 1.80 GHz);
  • Dual Core (Sandy Bridge, 32 nm, 17-35 W)
Mobile Celeron: B800 (2M Cache, 1.50 GHz), B810 (2M Cache, 1.60 GHz), B815 (2M Cache, 1.60 GHz), B820 (2M Cache, 1.70 GHz), B830 (2M Cache, 1.80 GHz), B840 (2M Cache, 1.90 GHz);
Mobile Pentium: B940 (2M Cache, 2.00 GHz, 35W), B950 (2M Cache, 2.10 GHz, 35W), B960 (2M Cache, 2.20 GHz, 35W), B970 (2M Cache, 2.30 GHz), B980 (2M Cache, 2.40 GHz), B987 (2M Cache, 1.50 GHz);
  • Dual Core (Ivy Bridge, 22 nm, 35 W)
Mobile Celeron: 1000M (2M Cache, 1.80 GHz), 1005M (2M Cache, 1.90 GHz), 1020M (2M Cache, 2.10 GHz);
Mobile Pentium: 2020M (2M Cache, 2.40 GHz), 2030M (2M Cache, 2.50 GHz).


List of mobile Intel® Core™ microprocessors of the 2nd and 3rd generation Sandy Bridge / Ivy Bridge
Socket G2 (rPGA988B) for Mobile Intel HM77 Chipset (SLJ8C), Intel HM76 Chipset (SLJ8E), Intel HM75 Chipset (SLJ8F)

Chipsets of Intel HM76 and Intel HM75 don't support processors Core i7-3920XM , Core i7-3940XM.

  • Single Core (Sandy Bridge, 32 nm, 35 W)
Mobile Celeron: B710 (1.5M Cache, 1.60 GHz), B720 (1.5M Cache, 1.70 GHz), B730 (1.5M Cache, 1.80 GHz);
  • Dual Core (Sandy Bridge, 32 nm, 17-35 W)
Mobile Celeron: B800 (2M Cache, 1.50 GHz), B810 (2M Cache, 1.60 GHz), B815 (2M Cache, 1.60 GHz), B820 (2M Cache, 1.70 GHz), B830 (2M Cache, 1.80 GHz), B840 (2M Cache, 1.90 GHz);
Mobile Pentium: B940 (2M Cache, 2.00 GHz, 35W), B950 (2M Cache, 2.10 GHz, 35W), B960 (2M Cache, 2.20 GHz, 35W), B970 (2M Cache, 2.30 GHz), B980 (2M Cache, 2.40 GHz), B987 (2M Cache, 1.50 GHz);
Core i3: 2308M, 2310M (3M Cache, 2.10 GHz), 2312M (3M Cashe, 2.1 GHz), 2328M (3M Cashe, 2.2 GHz), 2330E (3M Cashe, 2.2 GHz), 2330M (3M Cache, 2.20 GHz), 2348M (3M Cashe, 2.3 GHz), 2350M (3M Cashe, 2.3 GHz), 2370M (3M Cashe, 2.4 GHz);
Core i5: 2410M (3M Cache, 2.90 GHz), 2430M (3M Cache, 3.00 GHz), 2450M (3M Cache, 3.10 GHz), 2510E (3M Cache, 3.10 GHz), 2520M (3M Cache, 3.20 GHz), 2540M (3M Cache, 3.30 GHz);
Core i7: 2620M (4M Cache, 3.40 GHz), 2640M (4M Cache, 3.50 GHz);
  • Dual Core (Ivy Bridge, 22 nm, 35 W)
Mobile Celeron: 1000M (2M Cache, 1.80 GHz), 1005M (2M Cache, 1.90 GHz), 1020M (2M Cache, 2.10 GHz);
Mobile Pentium: 2020M (2M Cache, 2.40 GHz), 2030M (2M Cache, 2.50 GHz);
Core i3: 3110M (3M Cache, 2.40 GHz), 3120ME (3M Cache, 2.40 GHz), 3120M (3M Cache, 2.50 GHz), 3130M (3M Cache, 2.60 GHz);
Core i5: 3210M (3M Cache, 3.10 GHz), 3230M (3M Cache, 3.20 GHz), 3320M (3M Cache, 3.30 GHz), 3340M (3M Cache, 3.40 GHz), 3360M (3M Cache, 3.50 GHz), 3380M (3M Cache, 3.60 GHz);
Core i7: 3520M (4M Cache, 3.60 GHz), 3540M (4M Cache, 3.70 GHz);
  • Quad Core (Sandy Bridge, 32 nm, 40-55 W)
Core i7: 2630QM (6M Cache, 2.90 GHz), 2670QM (6M Cache, 3.10 GHz), 2710QE (6M Cache, 3.00 GHz), 2720QM (6M Cache, up to 3.30 GHz), 2760QM (6M Cache, 3.50 GHz), 2820QM (8M Cache, 3.40 GHz), 2860QM (8M Cache, 3.60 GHz), 2920XM (8M Cache, 3.50 GHz), 2960XM (8M Cache, 3.70 GHz);
  • Quad Core (Ivy Bridge, 22 nm, 35-55 W)
Core i7: 3610QM (6M Cache, 3.30 GHz), 3612QM (6M Cache, 3.10 GHz), 3630QM (6M Cache, 3.40 GHz), 3632QM (6M Cache, 3.20 GHz), 3720QM (6M Cache, 3.60 GHz), 3740QM, 3820QM (8M Cache, 3.70 GHz), 3840QM (8M Cache, 3.80 GHz), 3920XM (8M Cache, 3.80 GHz), 3940XM (8M Cache, 3.90 GHz).


CPUs Intel® Core™ 4th gen

List of mobile Intel® Core™ microprocessors of the 4th generation Haswell (22nm)
Socket G3 (rPGA 946B/947,FCPGA 946) for Intel HM87 Chipset (SR17D), Intel HM86 Chipset (SR17E)

  • Dual Core (Haswell, 22 nm, 37 W)
Mobile Celeron 2950M (2M Cache, 2 GHz);
Mobile Pentium 3550M (2M Cache, 2.3 GHz);
Core i3: 4000M (3M Cache, 2.4 GHz), 4100M (3M Cache, 2.5 GHz);
Core i5: 4000M (3M Cache, 2.5 GHz), 4300M (3M Cache, 2.6 GHz), 4330M (3M Cache, 2.8 GHz);
Core i7- 4600M (4M Cache, 2.9 GHz).
  • Dual Core (Haswell Refresh, 22 nm, 37 W)
Mobile Celeron 2970M (2M Cache, 2.2 GHz);
Mobile Pentium 3560M (2M Cache, 2.4 GHz);
Core i3: 4010M (3M Cache, 2.5 GHz), 4110M (3M Cache, 2.6 GHz);
Core i5: 4210M (3M Cache, 2.6 GHz), 4310M (3M Cache, 2.7 GHz), 4340M (3M Cache, 2.9 GHz);
Core i7- 4610M (4M Cache, 3 GHz).
  • Quad Core (Haswell, 22 nm, 37-57 W)
Core i7: 4700MQ (6M Cache, 2.4 GHz), 4702MQ (6M Cache, 2.2 GHz), 4800MQ (6M Cache, 2.7 GHz), 4900MQ (8M Cache, 2.8 GHz), 4930MX (8M Cache, 3 GHz).
  • Quad Core (Haswell Refresh, 22 nm, 37-57 W)
Core i7: 4710MQ (6M Cache, 2.5 GHz), 4712MQ (6M Cache, 2.3 GHz), 4810MQ (6M Cache, 2.8 GHz), 4910MQ (8M Cache, 2.9 GHz), 4940MX (8M Cache, 3.1 GHz).

Since architecture of Broadwell the Intel® company makes mobile processors only in BGA casing (don't use a socket, processors are unsoldered directly on the motherboard). Therefore the possibility of changeover of BGA processors is absent.

If you need the help in a choice of the suitable processor - you can ask a question in shape for comments.

For obtaining the response to a question:

  1. Attentively read article;
  2. Specify modification of the south bridge which is set in a notebook.

Comments that do not comply or do not relate to the article topic will not be published!
